Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Efficiency - Testing | 100mW/100mm [1] |
| Efficiency - Type | Sound Pressure Level (SPL) [1] |
| Efficiency - dBA | 88.00 [1] |
| Mfr | Soberton Inc. [1] |
| Frequency - Self Resonant | 800Hz [1] |
| Frequency Range | 800 Hz ~ 20 kHz [1] |
| Height - Seated (Max) | 0.157" (4.00mm) [1] |
| Impedance | 8 Ohms [1] |
| Product Status | Active [1] |
| Operating Temperature | -20°C ~ 60°C [1] |
| Material - Cone | Polyester, Polyethylene Terephthalate (PET) [1] |
| Material - Magnet | Nd-Fe-B [1] |
| Port Location | Top [1] |
| Power - Max | 1 W [1] |
| Power - Rated | 800 mW [1] |
| Series | SP Micro Speaker [1] |
| Shape | Round [1] |
| Size / Dimension | 0.787" Dia (20.00mm) [1] |
| Technology | Magnetic [1] |
| Termination | Solder Eyelet(s) [1] |
| Type | General Purpose [1] |
Specification references[1]Soberton Inc. SP-2004Y vendor product record ↗
