Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Efficiency - Testing | 100mm [1] |
| Efficiency - Type | Sound Pressure Level (SPL) [1] |
| Efficiency - dBA | 89.00 [1] |
| Mfr | DB Unlimited [1] |
| Frequency - Self Resonant | 450Hz [1] |
| Frequency Range | 450 Hz ~ 20 kHz [1] |
| Height - Seated (Max) | 0.228" (5.80mm) [1] |
| Impedance | 8 Ohms [1] |
| Product Status | Active [1] |
| Operating Temperature | -40°C~70°C [1] |
| Material - Cone | Cloth [1] |
| Port Location | Top [1] |
| Power - Max | 2 W [1] |
| Power - Rated | 1 W [1] |
| Shape | Rectangular [1] |
| Size / Dimension | 1.575" L x 0.787" W (40.00mm x 20.00mm) [1] |
| Technology | Magnetic [1] |
| Termination | Solder Pads [1] |
| Type | General Purpose [1] |
Specification references[1]DB Unlimited SC400408-1 vendor product record ↗
