Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Air Flow | 1200.0 CFM (33.60m³/min) [1] |
| Approval Agency | cURus, TUV [1] |
| Bearing Type | Ball [1] |
| Base Product Number | OD280 [1] |
| Fan Type | Tubeaxial [1] |
| Lifetime @ Temp. | 85000 Hrs @ 35°C [1] |
| Material - Blade | Thermoplastic, Fiberglass Reinforced [1] |
| Material - Frame | Aluminum [1] |
| Mfr | Orion Fans [1] |
| Noise | 72.0dB [1] |
| Operating Temperature | 5~149°F(-15~65°C) [1] |
| Power (Watts) | 104 W [1] |
| Product Status | Active [1] |
| RPM | 2550 RPM [1] |
| Series | OD280 [1] |
| Size / Dimension | Square - 280mm L x 280mm H [1] |
| Static Pressure | 0.900 in H2O (224.2 Pa) [1] |
| Termination | 2 Wire Leads [1] |
| Voltage - Rated | 24VDC [1] |
| Voltage Range | 18 ~ 27VDC [1] |
| Width | 89.00mm [1] |
Specification references[1]Orion Fans OD280-24HB vendor product record ↗
