Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Air Flow | 133.0 CFM (3.72m³/min) [1] |
| Approval Agency | cURus, TUV [1] |
| Bearing Type | Ball [1] |
| Base Product Number | OD127 [1] |
| Current Rating (Amps) | 0.170A [1] |
| Fan Type | Tubeaxial [1] |
| Lifetime @ Temp. | 60000 Hrs @ 45°C [1] |
| Material - Blade | Polybutylene Terephthalate (PBT), Fiberglass Reinforced [1] |
| Material - Frame | Polybutylene Terephthalate (PBT), Fiberglass Reinforced [1] |
| Mfr | Orion Fans [1] |
| Noise | 30.0dB [1] |
| Operating Temperature | -4~167°F(-20~75°C) [1] |
| Product Status | Active [1] |
| RPM | 2500 RPM [1] |
| Series | OD127 [1] |
| Size / Dimension | Square - 127mm L x 127mm H [1] |
| Static Pressure | 0.230 in H2O (57.3 Pa) [1] |
| Termination | 2 Wire Leads [1] |
| Voltage - Rated | 48VDC [1] |
| Voltage Range | 22 ~ 55VDC [1] |
| Width | 38.50mm [1] |
Specification references[1]Orion Fans OD127-48LB vendor product record ↗
