Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Backlight | LED [1] |
| Character Format | 5 x 8 Dots [1] |
| Controller Type | KS0066 [1] |
| Character Size | 4.74mm H x 2.95mm W [1] |
| Display Format | 16 x 4 [1] |
| Dot Size | 0.55mm W x 0.55mm H [1] |
| Display Mode | Transflective [1] |
| Display Type | STN - Super-Twisted Nematic, TN - Twisted Nematic [1] |
| Mfr | AZ Displays [1] |
| Operating Temperature | -20°C~70°C [1] |
| Outline L x W x H | 87.00mm x 60.00mm x 9.50mm [1] |
| Product Status | Active [1] |
| Series | ACM1604D [1] |
| Viewing Area | 61.80mm L x 25.20mm W [1] |
| Voltage - Supply | 2.7V ~ 5.5V [1] |
Specification references[1]AZ Displays ACM1604D-FL-YBW vendor product record ↗
