Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Base Product Number | ACJS [2] |
| Body Color | Black [2] |
| Connector Type | Phone Jack, Dual [2] |
| Contact Material | Brass [2] |
| Contact Material - Plating | Tin [2] |
| Current Rating (Amps) | 10 A [2] |
| Gender | Female [2] |
| Housing Material | Polyamide (PA66), Nylon 6/6, Glass Filled [2] |
| Features | Mounting Hardware, Thread Lock [2] |
| Industry Recognized Mating Diameter | 3.50mm (0.141", 1/8", Mini Plug) - Headphone, 6.35mm (0.250", 1/4") - Headphone [2] |
| Internal Switch(s) | Three Switches [2] |
| Mfr | Amphenol Audio [2] |
| Mounting Type | Panel Mount, Through Hole, Right Angle [2] |
| Number of Positions/Contacts | 3 Conductors, 6 Contacts [2] |
| Operating Temperature | -25°C ~ 70°C [2] |
| Product Status | Active [2] |
| Series | XLRSeries™ AC [2] |
| Shielding | Unshielded [2] |
| Signal Lines | Stereo (3 Conductor, TRS) [2] |
| Termination | Kinked Pin, Solder [2] |
| Voltage - Rated | 34V [2] |
