Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Base Product Number | ACJM [1] |
| Body Color | Black [1] |
| Connector Type | Phone Jack [1] |
| Contact Material | Brass [1] |
| Contact Material - Plating | Tin [1] |
| Current Rating (Amps) | 10 A [1] |
| Gender | Female [1] |
| Housing Material | Polyamide (PA66), Nylon 6/6, Glass Filled [1] |
| Features | Mounting Hardware, Thread Lock [1] |
| Industry Recognized Mating Diameter | 6.50mm [1] |
| Internal Switch(s) | Does Not Contain Switch [1] |
| Mfr | Amphenol Audio [1] |
| Mounting Type | Panel Mount, Through Hole [1] |
| Number of Positions/Contacts | 2 Conductors, 2 Contacts [1] |
| Operating Temperature | -25°C ~ 70°C [1] |
| Product Status | Active [1] |
| Series | XLRSeries™ AC [1] |
| Shielding | Unshielded [1] |
| Signal Lines | Mono [1] |
| Termination | Solder Eyelet(s) [1] |
| Voltage - Rated | 34V [1] |
Specification references[1]Amphenol Audio ACJM-MIV-2 vendor product record ↗
