Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Accuracy - Voltmeter; Ammeter | 0.5% + 1 count [2] |
| Base Product Number | Z10-20 [2] |
| Current - Output | 0 ~ 20A [2] |
| Current Regulation - Line | 2mA + 0.01% [2] |
| Current Regulation - Load | 5mA + 0.01% [2] |
| Display Type | Digital [2] |
| Features | GPIB, Programmable, RS232, RS485 and USB Interface [2] |
| Manufacturer | TDK-Lambda [2] |
| Number of Characters | 4 (2) [2] |
| Number of Outputs | 1 [2] |
| Part Status | Active [2] |
| Power (Watts) | 200W [2] |
| Ripple | 5mV [2] |
| Series | Z+ [2] |
| Size / Dimension | 13.780" L x 4.134" W x 3.268" H (350.00mm x 105.00mm x 83.00mm) [2] |
| Type | Bench (AC to DC) [2] |
| Voltage - Output | 0 ~ 10VDC [2] |
| Voltage - Supply | 85 ~ 265VAC [2] |
| Voltage Regulation - Line | 2mV + 0.01% [2] |
| Voltage Regulation - Load | 2mV + 0.01% [2] |
| Weight | 5.3 lbs (2.4 kg) [2] |
Specification references[1]Z10-20-IEEE-U delivered document ↗[2]TDK-Lambda Z10-20-IEEE-U vendor product record ↗
