Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Air Flow | 25.0 CFM (0.700m³/min) [1] |
| Bearing Type | Ball [1] |
| Base Product Number | XYW03628012 [1] |
| Current Rating (Amps) | 1.00A [1] |
| Fan Type | Tubeaxial [1] |
| Lifetime @ Temp. | 65000 Hrs @ 40°C [1] |
| Material - Blade | Polybutylene Terephthalate (PBT) [1] |
| Material - Frame | Polybutylene Terephthalate (PBT) [1] |
| Mfr | YS TECH USA [1] |
| Noise | 63.0dB(A) [1] |
| Power (Watts) | 12 W [1] |
| Product Status | Active [1] |
| RPM | 23000 RPM [1] |
| Series | XYW03628 [1] |
| Size / Dimension | Square - 36mm L x 36mm H [1] |
| Static Pressure | 2.600 in H2O (647.7 Pa) [1] |
| Termination | 2 Wire Leads [1] |
| Voltage - Rated | 12VDC [1] |
| Voltage Range | 7 ~ 13.2VDC [1] |
| Width | 28.00mm [1] |
Specification references[1]YS TECH USA XYW03628012BSS-12 vendor product record ↗
