Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Applications | General Purpose [1] |
| Capacitance | 8.2 mF [1] |
| ESR (Equivalent Series Resistance) | 12mOhm @ 100Hz [1] |
| Lead Spacing | 1.240" (31.50mm) [1] |
| Height - Seated (Max) | 3.898" (99.00mm) [1] |
| Lifetime @ Temp. | 8000 Hrs @ 85°C [1] |
| Impedance | 15 mOhms [1] |
| Mfr | AIC tech Inc. [1] |
| Mounting Type | Chassis Mount [1] |
| Operating Temperature | -40°C~85°C [1] |
| Product Status | Active [1] |
| Polarization | Polar [1] |
| Ripple Current @ High Frequency | 37.24 A @ 10 kHz [1] |
| Ripple Current @ Low Frequency | 26.6 A @ 120 Hz [1] |
| Series | VFL [1] |
| Size / Dimension | 3.543" Dia (90.00mm) [1] |
| Tolerance | ±20% [1] |
| Voltage - Rated | 400 V [1] |
Specification references[1]AIC tech Inc. VFL2G822YF097 vendor product record ↗
