Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Air Flow | 0.218 CFM (0.006m³/min) [1] |
| Approval Agency | CE [1] |
| Bearing Type | Vapo-Bearing™ [1] |
| Base Product Number | UF3C3 [1] |
| Current Rating (Amps) | 0.097A [1] |
| Fan Type | Tubeaxial [1] |
| Features | Auto Restart, Speed Sensor (Tach) [1] |
| Ingress Protection | IP55 - Dust Protected, Water Resistant [1] |
| Material - Blade | Liquid Crystal Polymer (LCP) [1] |
| Material - Frame | Liquid Crystal Polymer (LCP) [1] |
| Mfr | Sunon Fans [1] |
| Noise | 28.3dB(A) [1] |
| Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) [1] |
| Power (Watts) | 300 mW [1] |
| Product Status | Active [1] |
| RPM | 16500 RPM [1] |
| Series | MagLev® UF, Mighty Mini [1] |
| Size / Dimension | Square - 12mm L x 12mm H [1] |
| Static Pressure | 0.076 in H2O (18.9 Pa) [1] |
| Termination | 3 Wire Leads [1] |
| Voltage - Rated | 3VDC [1] |
| Voltage Range | 2 ~ 3.5VDC [1] |
| Weight | 0.002 lb (0.91 g) [1] |
| Width | 3.00mm [1] |
Specification references[1]Sunon Fans UF3C3-500TC vendor product record ↗
