Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Current - Output | 3A [1] |
| Base Product Number | TPS5430 [1] |
| Frequency - Switching | 500kHz [1] |
| Function | Step-Down [1] |
| Mfr | Texas Instruments [1] |
| Mounting Type | Surface Mount [1] |
| Number of Outputs | 1 [1] |
| Operating Temperature | -40°C~125°C(TJ) [1] |
| Output Configuration | Positive [1] |
| Output Type | Adjustable [1] |
| Product Status | Discontinued at Digi-Key [1] |
| Synchronous Rectifier | No [1] |
| Topology | Buck [1] |
| Voltage - Input (Max) | 36V [1] |
| Voltage - Input (Min) | 5.5V [1] |
| Voltage - Output (Min/Fixed) | 1.221V [1] |
| Voltage - Output (Max) | 32.04V [1] |
Specification references[1]Texas Instruments TPS5430DDAG4 vendor product record ↗
