SWC-5.0-23 vendor-delivered product or package visual

Representative package visualProduct referenceVendor-delivered DigiKey product/package image

Exact MPN15 sourced attributes1 source document

Amgis, LLC · exact orderable part

SWC-4.5-19

FIXED IND 19UH 4.5A 20 MOHM TH

Current Rating (Amps): 4.5 A
DC Resistance (DCR): 20mOhm
Height - Seated (Max): 0.937" (23.80mm)
Inductance: 19 µH
Inductance Frequency - Test: 10 kHz
Material - Core: Iron Powder

Original manufacturerCommercial terms confirmed per lot

ManufacturerAmgis, LLC

Package / caseRadial, Vertical (Open)

Mounting typeunknown

PackingBulk

Technical parameters

Technical specifications

15 normalized values · 1 validated source

Report a data issue

SWC-4.5-19 technical parameters
Parameter	Value
Current Rating (Amps)	4.5 A [1]
DC Resistance (DCR)	20mOhm [1]
Height - Seated (Max)	0.937" (23.80mm) [1]
Inductance	19 µH [1]
Inductance Frequency - Test	10 kHz [1]
Material - Core	Iron Powder [1]
Mfr	Amgis, LLC [1]
Mounting Type	Through Hole [1]
Operating Temperature	-40°C~125°C [1]
Product Status	Active [1]
Series	SW [1]
Shielding	Unshielded [1]
Size / Dimension	0.827" L x 0.449" W (21.00mm x 11.40mm) [1]
Tolerance	±20% [1]
Type	Toroidal [1]

Specification references[1]Amgis, LLC SWC-4.5-19 vendor product record ↗
