Representative package visualProduct referenceVendor-delivered DigiKey product/package image1 of 2

Exact MPN12 sourced attributes1 source document

STMicroelectronics · exact orderable part

STPS20H100CG

Name: STPS20H100CG
Brand: STMicroelectronics

DIODE ARR SCHOTT 100V 10A D2PAK

Original manufacturerCommercial terms confirmed per lot

ManufacturerSTMicroelectronics

Package / caseTO-263-3, D²Pak (2 Leads + Tab), TO-263AB

Mounting typeunknown

PackingTube

Technical parameters

Technical specifications

12 normalized values · 1 validated source

STPS20H100CG technical parameters
Parameter	Value
Base Product Number	STPS20 [1]
Current - Average Rectified (Io) (per Diode)	10A [1]
Current - Reverse Leakage @ Vr	4.5 µA @ 100 V [1]
Diode Configuration	1 Pair Common Cathode [1]
Mfr	STMicroelectronics [1]
Mounting Type	Surface Mount [1]
Operating Temperature - Junction	175°C (Max) [1]
Product Status	Active [1]
Speed	Fast Recovery =< 500ns, > 200mA (Io) [1]
Technology	Schottky [1]
Voltage - DC Reverse (Vr) (Max)	100 V [1]
Voltage - Forward (Vf) (Max) @ If	770 mV @ 10 A [1]
