Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Actual Diameter | 0.091" (2.30mm) [2] |
| Body Color | Silver [2] |
| Connector Type | Phone Plug [2] |
| Body Material | Brass [2] |
| Contact Material | Brass [2] |
| Contact Material - Plating | Nickel [2] |
| Current Rating (Amps) | 1 A [2] |
| Gender | Male [2] |
| Insulation Color | White [2] |
| Industry Recognized Mating Diameter | 2.50mm (0.094", 3/32", Sub Mini, Miniature) - Headphone [2] |
| Internal Switch(s) | Does Not Contain Switch [2] |
| Mating Length/Depth | 0.433" (11.00mm) [2] |
| Mfr | CUI Devices [2] |
| Mounting Type | Free Hanging (In-Line) [2] |
| Number of Positions/Contacts | 4 Conductors, 4 Contacts [2] |
| Operating Temperature | -25°C~70°C [2] |
| Product Status | Active [2] |
| Shielding | Unshielded [2] |
| Signal Lines | Stereo (4 Conductor, TRRS) [2] |
| Termination | Solder [2] |
| Voltage - Rated | 12VDC [2] |
Specification references[1]SP-2541-WT delivered document ↗[2]CUI Devices SP-2541-WT vendor product record ↗
