Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Applications | ITE (Commercial) [1] |
| Approval Agency | CE [1] |
| Current - Output (Max) | 33mA, 33mA [1] |
| Efficiency | 80% [1] |
| Mfr | HenLv Power [1] |
| Mounting Type | Through Hole [1] |
| Number of Outputs | 2 [1] |
| Operating Temperature | -40°C ~ 85°C (With Derating) [1] |
| Power (Watts) | 1 W [1] |
| Part Status | Active [1] |
| Size / Dimension | 0.77" L x 0.28" W x 0.39" H (19.6mm x 7.0mm x 10.0mm) [1] |
| Type | Isolated Module [1] |
| Voltage - Input (Max) | 12.6V [1] |
| Voltage - Output 2 | -15V [1] |
| Voltage - Input (Min) | 11.4V [1] |
| Voltage - Isolation | 3 kV [1] |
| Voltage - Output 1 | 15V [1] |
Specification references[1]HenLv Power S12D15-1WH2 vendor product record ↗
