Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Adapter Series | N to 4.1/9.5 [1] |
| Adapter Type | Jack to Jack [1] |
| Base Product Number | RFN-1047 [1] |
| Body Material | Brass [1] |
| Body Finish | White Bronze [1] |
| Center Contact Material | Phosphor Bronze [1] |
| Center Gender | Female to Female [1] |
| Conversion Type | Between Series [1] |
| Center Contact Plating | Silver [1] |
| Convert From (Adapter End) | 4.1/9.5 Jack, Female Socket [1] |
| Convert To (Adapter End) | N Jack, Female Socket [1] |
| Fastening Type | Threaded, Threaded [1] |
| Frequency - Max | 7.5 GHz [1] |
| Impedance | 50Ohm [1] |
| Dielectric Material | Polytetrafluoroethylene (PTFE) [1] |
| Mfr | RF Industries [1] |
| Mounting Type | Free Hanging (In-Line) [1] |
| Product Status | Active [1] |
| Insertion Loss | 0.05dB [1] |
| Style | Straight [1] |
| Mating Cycles | 500 [1] |
| Operating Temperature | -55°C~85°C [1] |
Specification references[1]RF Industries RFN-1047-4 vendor product record ↗
