Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Type | Enclosed [2] |
| Applications | Household Appliances, ITE (Commercial), Medical [2] |
| Voltage - Input | 85 ~ 305 VAC, 120 ~ 431 VDC [2] |
| Approval Agency | CB, CE, cURus, EAC, UKCA [2] |
| Voltage - Output 1 | 24V [2] |
| Current - Output (Max) | 1.25A [2] |
| Mounting Type | Through Hole [2] |
| Efficiency | 89% [2] |
| Line Regulation | ±0.5% [2] |
| Load Regulation | ±1% [2] |
| Manufacturer | Recom Power [2] |
| Number of Outputs | 1 [2] |
| Operating Temperature | -40°C ~ 90°C (With Derating) [2] |
| Part Status | Active [2] |
| Power (Watts) | 30 W [2] |
| Size / Dimension | 2.07" L x 1.57" W x 1.00" H (52.5mm x 40.0mm x 25.5mm) [2] |
| Series | MEDLINE RACM30-K/277 (30W) [2] |
| Standard Number | 60335-1; 60601-1; 61010-1; 62368-1 [2] |
