Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Applications | ITE (Commercial) [1] |
| Base Product Number | R1S-0505 [1] |
| Current - Output (Max) | 200mA [1] |
| Efficiency | 78% [1] |
| Features | SCP [1] |
| Mfr | Recom Power [1] |
| Mounting Type | Surface Mount [1] |
| Number of Outputs | 1 [1] |
| Operating Temperature | -40°C ~ 100°C [1] |
| Power (Watts) | 1 W [1] |
| Product Status | Active [1] |
| Series | ECONOLINE R1S (1W) [1] |
| Size / Dimension | 0.50" L x 0.42" W x 0.28" H (12.8mm x 10.7mm x 7.0mm) [1] |
| Type | Isolated Module [1] |
| Voltage - Input (Max) | 5.5V [1] |
| Voltage - Input (Min) | 4.5V [1] |
| Voltage - Isolation | 1 kV [1] |
| Voltage - Output 1 | 5V [1] |
Specification references[1]Recom Power R1S-0505-R vendor product record ↗
