Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Applications | ITE (Commercial) [1] |
| Current - Output (Max) | 33mA [1] |
| Efficiency | 62% [1] |
| Features | SCP [1] |
| Mfr | Recom Power [1] |
| Mounting Type | Surface Mount [1] |
| Number of Outputs | 1 [1] |
| Operating Temperature | -40°C~100°C [1] |
| Power (Watts) | 500 mW [1] |
| Product Status | Active [1] |
| Series | ECONOLINE R0.5Z (0.5W) [1] |
| Size / Dimension | 0.60" L x 0.42" W x 0.28" H (15.2mm x 10.7mm x 7.0mm) [1] |
| Type | Isolated Module [1] |
| Voltage - Input (Max) | 5.25V [1] |
| Voltage - Input (Min) | 4.75V [1] |
| Voltage - Isolation | 1 kV [1] |
| Voltage - Output 1 | 15V [1] |
Specification references[1]Recom Power R0.5Z-0515 vendor product record ↗
