Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Air Flow | 25.9 CFM (0.725m³/min) [1] |
| Bearing Type | Ball [1] |
| Base Product Number | QYW09225012 [1] |
| Current Rating (Amps) | 0.035A [1] |
| Fan Type | Tubeaxial [1] |
| Lifetime @ Temp. | 80000 Hrs @ 40°C [1] |
| Material - Blade | Polybutylene Terephthalate (PBT) [1] |
| Material - Frame | Polybutylene Terephthalate (PBT) [1] |
| Mfr | YS TECH USA [1] |
| Noise | 16.7dB(A) [1] |
| Power (Watts) | 420 mW [1] |
| Product Status | Active [1] |
| RPM | 2000 RPM [1] |
| Series | QYW9225 [1] |
| Size / Dimension | Square - 92mm L x 92mm H [1] |
| Static Pressure | 0.083 in H2O (20.6 Pa) [1] |
| Termination | 2 Wire Leads [1] |
| Voltage - Rated | 12VDC [1] |
| Voltage Range | 7 ~ 13.2VDC [1] |
| Width | 25.00mm [1] |
Specification references[1]YS TECH USA QYW09225012BL-12 vendor product record ↗
