Representative package visualProduct reference1 of 2

Exact MPN23 sourced attributes1 manufacturer document

QST · exact orderable part

QMI8658C

Six-axis IMU with I3C, I2C and SPI interfaces, ±2 to ±16 g accelerometer range and ±16 to ±1024 dps gyroscope range.

Number of Axes: 6
Interface: I3C; I2C; 3-/4-wire SPI
Accelerometer Full-Scale Range: ±2 g, ±4 g, ±8 g, ±16 g
Gyroscope Full-Scale Range: ±16 dps to ±1024 dps
Minimum Supply Voltage: 1.71 V
Package / Case: LGA14

China-origin manufacturerCommercial terms confirmed per lot

ManufacturerQST

Package / caseLGA14 2.5 × 3.0 × 0.86 mm

Mounting typesurface mount

PackingTape and reel

Temperature grade-40 to 85 °C

Technical parameters

Technical specifications

23 normalized values · 1 manufacturer source

Report a data issue

QMI8658C technical parameters
Parameter	Value
Number of Axes	6 [1]
Interface	I3C; I2C; 3-/4-wire SPI [1]
Minimum Supply Voltage	1.71 V [1]
Maximum Supply Voltage	3.6 V [1]
Package / Case	LGA14 [1]
Accelerometer Full-Scale Range	±2 g, ±4 g, ±8 g, ±16 g [1]
Gyroscope Full-Scale Range	±16 dps to ±1024 dps [1]
Typical Accelerometer Noise Density	150 µg/√Hz typical, high-resolution mode [1]
Typical Gyroscope Noise Density	15 mdps/√Hz typical, high-resolution mode [1]
FIFO Capacity	1536 bytes [1]
Embedded Motion Functions	Pedometer; tap; any-motion; no-motion; significant-motion; wake-on-motion [1]
Embedded Temperature Sensor	Yes [1]
Operating Temperature Range	-40 to 85 °C [1]
Maximum SPI Clock	15 MHz [1]
Maximum I2C Clock	400 kHz [1]
Maximum I3C SDR Clock	12.5 MHz [1]
ESD Rating (HBM)	2000 V [1]
ESD Rating (CDM)	500 V [1]
Typical System Turn-On Time	15 ms [1]
Package Dimensions	2.5 × 3.0 × 0.86 mm [1]
Pin Count	14 [1]
Accelerometer Output Width	16 bit [1]
Gyroscope Output Width	16 bit [1]

Specification references[1]QST QMI8658C Datasheet, Rev A; history through 1.0, 2022-06-20 ↗

Product overview

QMI8658C at a glance

QST QMI8658C is an exact orderable imu sensors device in LGA14 2.5 × 3.0 × 0.86 mm. The reviewed technical record lists number of axes of 6 and interface of I3C; I2C; 3-/4-wire SPI.

Key features

Verified device capabilities

Number of Axes: 6 under the cited manufacturer conditions.
Interface: I3C; I2C; 3-/4-wire SPI under the cited manufacturer conditions.
Minimum Supply Voltage: 1.71 V under the cited manufacturer conditions.
Maximum Supply Voltage: 3.6 V under the cited manufacturer conditions.
Package / Case: LGA14 under the cited manufacturer conditions.

Applications

Where the device is used

Motion-sensing designs selected for the documented number of axes, interface, minimum supply voltage.

Ordering information

Exact code and packing

QMI8658C identifies the exact QST order code in LGA14 2.5 × 3.0 × 0.86 mm with Tape and reel packing recorded; current lot terms are confirmed in the quotation.

Design notes

Use the rating in context

Use the cited operating conditions for QMI8658C; do not convert an absolute maximum, headline rating or family-level value into an unconditional board-level guarantee.

Quotation and fulfillment

What is confirmed before an order

Commercial facts belong to the quoted lot. The catalog does not invent live stock, price, date code or lead time.

Exact-part check

Manufacturer, full suffix, package, quantity and requested documentation are captured in the RFQ.

Lot-level quotation

Price, available quantity, date code, condition and lead time are written into the quotation when confirmed.

Inspection request

Label, marking, packing and traceability requirements can be specified before shipment.

Shipping and payment

Shipping method, Incoterm and available payment route are agreed in the commercial offer.

Technical and ordering FAQ

Questions buyers ask about QMI8658C

Answers distinguish the IC itself from assembled modules and keep absolute limits separate from normal operating conditions.

What package does QMI8658C use?

QMI8658C is recorded in LGA14 2.5 × 3.0 × 0.86 mm. Confirm the complete suffix and packing in the quotation.

What is the documented number of axes?

The cited manufacturer record lists 6. Apply the source's test and operating conditions.

How should the interface be interpreted?

The normalized catalog value is I3C; I2C; 3-/4-wire SPI. The linked evidence controls its exact conditions and revision.

Does this page prove current QMI8658C stock?

No. Technical evidence identifies the device; stock, date code, price, MOQ and lead time require a current verified offer or quotation.

Can QMI8658C be replaced by a similar part without review?

No automatic drop-in claim is made. Compare electrical limits, package, pinout, functions and qualification before substitution.

Catalog relationships

Keep family and exact MPN intent separate.

This page describes one orderable part. A family page helps select suffixes but never carries assumed stock or a price.

ManufacturerQSTView brand page →CategoryIMU SensorsView category page →Part familyQMI8658Compare exact variants →

Related exact parts

Other published variants

Reviewed comparison paths

Evaluate alternatives without assuming drop-in compatibility

Every path below passed electrical, package, pinout, firmware and compliance review. The linked verdict controls; similarity alone is not approval.

Engineering validation required

QMI8658A

Select the exact version and validate its register map and driver against the target board.

Open evidence-backed comparison →

Ready to source

Request QMI8658C by quantity

Send the exact MPN, quantity and any date-code, packing or documentation requirements. You can also add more lines or upload a BOM.
