PXG-M15-24WS24 representative package visual — not an exact-product photograph

Representative package visual — not an exact-product photographProduct referenceVendor-delivered DigiKey product/package image

Exact MPN20 sourced attributes1 source document

TDK-Lambda · exact orderable part

PXG-M15-24WS24

DC DC CONVERTER 24V 15W

Type: Isolated Module
Number of Outputs: 1
Voltage - Input (Min): 9V
Voltage - Input (Max): 36V
Voltage - Output 1: 24V
Current - Output (Max): 625mA
Power (Watts): 15 W
Voltage - Isolation: 5 kV
Series: PXG-M (20W)

Original manufacturerCommercial terms confirmed per lot

ManufacturerTDK-Lambda

Package / case6-DIP Module

Mounting typeThrough Hole

PackingTube

Technical parameters

Technical specifications

20 normalized values · 1 validated source

Report a data issue

PXG-M15-24WS24 technical parameters
Parameter	Value
Applications	ITE (Commercial), Medical [1]
Base Product Number	PXG-M15 [1]
Approval Agency	CE [1]
Current - Output (Max)	625mA [1]
Efficiency	88% [1]
Features	Adjustable Output [1]
Mfr	TDK-Lambda [1]
Mounting Type	Through Hole [1]
Number of Outputs	1 [1]
Operating Temperature	-40°C ~ 105°C (With Derating) [1]
Power (Watts)	15 W [1]
Part Status	Active [1]
Series	PXG-M (20W) [1]
Size / Dimension	1.60" L x 1.00" W x 0.40" H (40.6mm x 25.4mm x 10.2mm) [1]
Type	Isolated Module [1]
Voltage - Input (Max)	36V [1]
Voltage - Input (Min)	9V [1]
Voltage - Isolation	5 kV [1]
Voltage - Output 1	24V [1]
Package / Case	6-DIP Module [1]

Specification references[1]TDK-Lambda PXG-M15-24WS24 vendor product record ↗
