Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Applications | ITE (Commercial), Medical [1] |
| Base Product Number | PXD-M30 [1] |
| Approval Agency | CE [1] |
| Current - Output (Max) | 3A, 3A [1] |
| Efficiency | 86.5% [1] |
| Features | Adjustable Output [1] |
| Mfr | TDK-Lambda [1] |
| Mounting Type | Through Hole [1] |
| Number of Outputs | 2 [1] |
| Operating Temperature | -40°C ~ 105°C (With Derating) [1] |
| Power (Watts) | 30 W [1] |
| Part Status | Active [1] |
| Series | PXD-M (30W) [1] |
| Size / Dimension | 2.00" L x 1.00" W x 0.40" H (50.8mm x 25.4mm x 10.2mm) [1] |
| Type | Isolated Module [1] |
| Voltage - Input (Max) | 75V [1] |
| Voltage - Output 2 | -5V [1] |
| Voltage - Input (Min) | 18V [1] |
| Voltage - Isolation | 5 kV [1] |
| Voltage - Output 1 | 5V [1] |
Specification references[1]TDK-Lambda PXD-M30-48WD05 vendor product record ↗
