Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Applications | Medical [1] |
| Base Product Number | PXC-M10 [1] |
| Current - Output (Max) | 2A [1] |
| Efficiency | 86.5% [1] |
| Features | OCP, OVP, SCP [1] |
| Mfr | TDK-Lambda [1] |
| Mounting Type | Through Hole [1] |
| Number of Outputs | 1 [1] |
| Operating Temperature | -40°C ~ 105°C [1] |
| Power (Watts) | 10 W [1] |
| Part Status | Active [1] |
| Series | PXC-M10 (10W) [1] |
| Size / Dimension | 1.25" L x 0.80" W x 0.40" H (31.8mm x 20.3mm x 10.2mm) [1] |
| Type | Isolated Module [1] |
| Voltage - Input (Max) | 36V [1] |
| Voltage - Input (Min) | 9V [1] |
| Voltage - Isolation | 5 kV [1] |
| Voltage - Output 1 | 5V [1] |
Specification references[1]TDK-Lambda PXC-M10-24WS05-A vendor product record ↗
