Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Applications | ITE (Commercial) [1] |
| Control Features | Enable, Active Low [1] |
| Base Product Number | PXB15 [1] |
| Current - Output (Max) | 1.3A [1] |
| Efficiency | 87% [1] |
| Features | Remote On/Off, OCP, OVP, SCP [1] |
| Mfr | TDK-Lambda [1] |
| Mounting Type | Through Hole [1] |
| Number of Outputs | 1 [1] |
| Operating Temperature | -40°C ~ 85°C [1] |
| Power (Watts) | 15 W [1] |
| Part Status | Active [1] |
| Series | PXB (15W) [1] |
| Size / Dimension | 1.00" L x 1.00" W x 0.39" H (25.4mm x 25.4mm x 9.9mm) [1] |
| Type | Isolated Module [1] |
| Voltage - Input (Max) | 75V [1] |
| Voltage - Input (Min) | 18V [1] |
| Voltage - Isolation | 1.6 kV [1] |
| Voltage - Output 1 | 12V [1] |
Specification references[1]TDK-Lambda PXB15-48WS12/NT vendor product record ↗
