Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| AC Voltage - Input | 85 ~ 264 VAC [1] |
| Applications | ITE (Commercial) [1] |
| Approval Agency | CE, UKCA, UL [1] |
| Current - Output (Max) | 2.5A [1] |
| Efficiency | 85% [1] |
| DC Voltage - Input (Max) | 370V [1] |
| Features | Adjustable Output, Universal Input [1] |
| DC Voltage - Input (Min) | 120V [1] |
| Input Type | AC or DC [1] |
| Mfr | Brainboxes [1] |
| Number of Outputs | 1 [1] |
| Operating Temperature | -40°C~70°C [1] |
| Power (Watts) | 60W [1] |
| Product Status | Active [1] |
| Series | PW-245 (60W) [1] |
| Size / Dimension | 2.28" L x 2.05" W x 3.65" H (58.0mm x 52.0mm x 92.7mm) [1] |
| Standard Number | 62368-1 [1] |
| Voltage - Isolation | 4 kV [1] |
| Voltage - Output 1 | 24V [1] |
Specification references[1]Brainboxes PW-245 vendor product record ↗
