Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Capacitance | 22 µF [1] |
| Applications | General Purpose [1] |
| Tolerance | ±20% [1] |
| ESR (Equivalent Series Resistance) | 150mOhm [1] |
| Height - Seated (Max) | 0.315" (8.00mm) [1] |
| Mfr | Elna America [1] |
| Lifetime @ Temp. | 2000 Hrs @ 105°C [1] |
| Mounting Type | Surface Mount [1] |
| Product Status | Active [1] |
| Operating Temperature | -55°C ~ 105°C [1] |
| Ripple Current @ High Frequency | 1 A @ 100 kHz [1] |
| Surface Mount Land Size | 0.409" L x 0.409" W (10.40mm x 10.40mm) [1] |
| Series | PVH [1] |
| Size / Dimension | 0.394" Dia (10.00mm) [1] |
| Type | Polymer [1] |
| Voltage - Rated | 35 V [1] |
Specification references[1]Elna America PVH-35V220MH80E-R2 vendor product record ↗
