Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Base Product Number | PSR1635 [1] |
| Cable Length | 500' (152.4m) [1] |
| Cable Width | 0.90" (22.86mm) [1] |
| Conductor Material | Copper, Bare [1] |
| Conductor Thickness | 0.003" (0.08mm) [1] |
| Current Rating (Amps) | 3 A [1] |
| Features | Conductor 1 Tinned [1] |
| Jacket (Insulation) Material | Polyester [1] |
| Jacket (Insulation) Thickness | 0.002" (0.05mm) [1] |
| Mfr | Parlex USA LLC [1] |
| Number of Conductors | 8 [1] |
| Operating Temperature | 105°C [1] |
| Pitch | 0.100" (2.54mm) [1] |
| Product Status | Active [1] |
| Ratings | UL Style 2643 [1] |
| Series | PSR1635 [1] |
| Voltage Rating | 300 V [1] |
| Wire Gauge | 27 AWG (Equivalent) [1] |
Specification references[1]Parlex USA LLC PSR1635-08 vendor product record ↗
