Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Connector Type | Header [2] |
| Mfr | SUPERIOR TECH [2] |
| Contact Finish - Mating | Gold [2] |
| Product Status | Active [2] |
| Contact Finish - Post | Gold [2] |
| Series | PHDD [2] |
| Contact Finish Thickness - Mating | Flash [2] |
| Contact Finish Thickness - Post | Flash [2] |
| Contact Length - Post | 0.157" (4.00mm) [2] |
| Contact Material | Brass [2] |
| Contact Length - Mating | 0.157" (4.00mm) [2] |
| Contact Shape | Square [2] |
| Contact Type | Male Pin [2] |
| Current Rating (Amps) | 2A [2] |
| Fastening Type | Push-Pull [2] |
| Features | Pick and Place [2] |
| Insulation Color | Black [2] |
| Insulation Height | 0.079" (2.00mm) [2] |
| Insulation Material | Plastic, Halogen Free [2] |
| Material Flammability Rating | UL94 V-0 [2] |
| Mounting Type | Surface Mount [2] |
| Number of Positions | 8 [2] |
| Number of Positions Loaded | All [2] |
| Number of Rows | 2 [2] |
| Overall Contact Length | 0.083" (2.10mm) [2] |
| Operating Temperature | -40°C~125°C [2] |
| Pitch - Mating | 0.079" (2.00mm) [2] |
| Row Spacing - Mating | 0.079" (2.00mm) [2] |
| Shrouding | Unshrouded [2] |
| Style | Board to Board [2] |
| Termination | Solder [2] |
