Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Connector Type | Header [1] |
| Mfr | SUPERIOR TECH [1] |
| Contact Finish - Mating | Gold [1] |
| Product Status | Active [1] |
| Contact Finish - Post | Gold [1] |
| Series | PHDD [1] |
| Contact Finish Thickness - Mating | Flash [1] |
| Contact Finish Thickness - Post | Flash [1] |
| Contact Length - Post | 0.154" (3.91mm) [1] |
| Contact Material | Brass [1] |
| Contact Length - Mating | 0.154" (3.91mm) [1] |
| Contact Shape | Square [1] |
| Contact Type | Male Pin [1] |
| Current Rating (Amps) | 2A [1] |
| Fastening Type | Push-Pull [1] |
| Insulation Color | Black [1] |
| Insulation Height | 0.157" (4.00mm) [1] |
| Insulation Material | Polybutylene Terephthalate (PBT) [1] |
| Material Flammability Rating | UL94 V-0 [1] |
| Mounting Type | Through Hole, Right Angle [1] |
| Number of Positions | 10 [1] |
| Number of Positions Loaded | All [1] |
| Number of Rows | 2 [1] |
| Overall Contact Length | 0.110" (2.80mm) [1] |
| Operating Temperature | -40°C~125°C [1] |
| Pitch - Mating | 0.079" (2.00mm) [1] |
| Row Spacing - Mating | 0.079" (2.00mm) [1] |
| Shrouding | Unshrouded [1] |
| Style | Board to Board [1] |
| Termination | Solder [1] |
Specification references[1]SUPERIOR TECH PHDD-RS010G1ABOPA-C072 vendor product record ↗
