Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Air Flow | 9.2 CFM (0.258m³/min) [1] |
| Approval Agency | CE, cURus, TUV, UR [1] |
| Bearing Type | Ball [1] |
| Base Product Number | OD4010 [1] |
| Current Rating (Amps) | 0.070A [1] |
| Fan Type | Tubeaxial [1] |
| Features | Auto Restart [1] |
| Lifetime @ Temp. | 60000 Hrs @ 45°C [1] |
| Material - Blade | Polybutylene Terephthalate (PBT) [1] |
| Material - Frame | Polybutylene Terephthalate (PBT) [1] |
| Mfr | Orion Fans [1] |
| Noise | 33.4dB [1] |
| Operating Temperature | -4~149°F(-20~65°C) [1] |
| Power (Watts) | 720 mW [1] |
| Product Status | Active [1] |
| RPM | 8000 RPM [1] |
| Series | OD4010 [1] |
| Size / Dimension | Square - 40mm L x 40mm H [1] |
| Static Pressure | 0.200 in H2O (49.8 Pa) [1] |
| Termination | 2 Wire Leads [1] |
| Voltage - Rated | 12VDC [1] |
| Voltage Range | 10.8 ~ 13.2VDC [1] |
| Weight | 0.441 lb (200.00 g) [1] |
| Width | 10.50mm [1] |
Specification references[1]Orion Fans OD4010-12HB vendor product record ↗
