Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Air Flow | 1050.0 CFM (29.40m³/min) [1] |
| Approval Agency | CE, cURus, TUV, UR [1] |
| Bearing Type | Ball [1] |
| Current Rating (Amps) | 7.50A [1] |
| Fan Type | Tubeaxial [1] |
| Lifetime @ Temp. | 85000 Hrs @ 35°C [1] |
| Material - Blade | Polybutylene Terephthalate (PBT) [1] |
| Material - Frame | Aluminum [1] |
| Mfr | Orion Fans [1] |
| Noise | 56.0dB(A) [1] |
| Operating Temperature | -4 ~ 149°F (-20 ~ 65°C) [1] |
| Power (Watts) | 90 W [1] |
| Product Status | Active [1] |
| RPM | 2150 RPM [1] |
| Series | OD280 [1] |
| Size / Dimension | Square - 280mm L x 280mm H [1] |
| Static Pressure | 0.650 in H2O (161.9 Pa) [1] |
| Termination | 2 Terminals [1] |
| Voltage - Rated | 12VDC [1] |
| Voltage Range | 11 ~ 13.8VDC [1] |
| Width | 89.00mm [1] |
Specification references[1]Orion Fans OD280-12MTB vendor product record ↗
