Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Air Flow | 161.0 CFM (4.51m³/min) [1] |
| Approval Agency | cURus, TUV [1] |
| Bearing Type | Ball [1] |
| Base Product Number | OD127 [1] |
| Current Rating (Amps) | 0.410A [1] |
| Fan Type | Tubeaxial [1] |
| Features | PWM Control [1] |
| Lifetime @ Temp. | 60000 Hrs @ 45°C [1] |
| Material - Blade | Polybutylene Terephthalate (PBT), Fiberglass Reinforced [1] |
| Material - Frame | Polybutylene Terephthalate (PBT), Fiberglass Reinforced [1] |
| Mfr | Orion Fans [1] |
| Noise | 53.0dB [1] |
| Operating Temperature | -4 ~ 167°F (-20 ~ 75°C) [1] |
| Product Status | Active [1] |
| RPM | 2950 RPM [1] |
| Series | OD127 [1] |
| Size / Dimension | Square - 127mm L x 127mm H [1] |
| Static Pressure | 0.350 in H2O (87.2 Pa) [1] |
| Termination | 3 Wire Leads [1] |
| Voltage - Rated | 24VDC [1] |
| Voltage Range | 11 ~ 28VDC [1] |
| Width | 38.50mm [1] |
Specification references[1]Orion Fans OD127-24MB5 vendor product record ↗
