Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Air Flow | 95.0 CFM (2.66m³/min) [1] |
| Approval Agency | cURus, TUV [1] |
| Bearing Type | Sleeve [1] |
| Base Product Number | OD1238 [1] |
| Current Rating (Amps) | 0.230A [1] |
| Fan Type | Tubeaxial [1] |
| Lifetime @ Temp. | 65000 Hrs @ 45°C [1] |
| Material - Blade | Polybutylene Terephthalate (PBT), Fiberglass Reinforced [1] |
| Material - Frame | Polybutylene Terephthalate (PBT), Fiberglass Reinforced [1] |
| Mfr | Orion Fans [1] |
| Noise | 41.0dB [1] |
| Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) [1] |
| Power (Watts) | 6 W [1] |
| Part Status | Active [1] |
| RPM | 2540 RPM [1] |
| Series | OD1238 [1] |
| Size / Dimension | Square - 120mm L x 120mm H [1] |
| Static Pressure | 0.230 in H2O (57.3 Pa) [1] |
| Termination | 2 Wire Leads [1] |
| Voltage - Rated | 24VDC [1] |
| Width | 38.50mm [1] |
Specification references[1]Orion Fans OD1238-24MS vendor product record ↗
