Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Air Flow | 123.9 CFM (3.47m³/min) [1] |
| Approval Agency | CE, cURus, TUV, UR [1] |
| Bearing Type | Ball [1] |
| Base Product Number | OD1238 [1] |
| Current Rating (Amps) | 0.500A [1] |
| Fan Type | Tubeaxial [1] |
| Features | Auto Restart [1] |
| Lifetime @ Temp. | 65000 Hrs @ 45°C [1] |
| Material - Blade | Polybutylene Terephthalate (PBT) [1] |
| Material - Frame | Polybutylene Terephthalate (PBT) [1] |
| Mfr | Orion Fans [1] |
| Noise | 44.1dB(A) [1] |
| Operating Temperature | -4~149°F(-20~65°C) [1] |
| Power (Watts) | 6 W [1] |
| Product Status | Active [1] |
| RPM | 2895 RPM [1] |
| Series | OD1238 [1] |
| Size / Dimension | Square - 120mm L x 120mm H [1] |
| Static Pressure | 0.469 in H2O (116.8 Pa) [1] |
| Termination | 2 Wire Leads [1] |
| Voltage - Rated | 12VDC [1] |
| Voltage Range | 9 ~ 13.8VDC [1] |
| Weight | 0.572 lb (259.45 g) [1] |
| Width | 38.00mm [1] |
Specification references[1]Orion Fans OD1238-12HB vendor product record ↗
