Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Air Flow | 120.0 CFM (3.36m³/min) [1] |
| Approval Agency | CE, cURus, TUV, UR [1] |
| Bearing Type | Ball [1] |
| Base Product Number | OD1225 [1] |
| Current Rating (Amps) | 0.320A [1] |
| Fan Type | Tubeaxial [1] |
| Features | Auto Restart [1] |
| Lifetime @ Temp. | 60000 Hrs @ 40°C [1] |
| Material - Blade | Polybutylene Terephthalate (PBT) [1] |
| Material - Frame | Polybutylene Terephthalate (PBT) [1] |
| Mfr | Orion Fans [1] |
| Noise | 42.0dB(A) [1] |
| Operating Temperature | -4~149°F(-20~65°C) [1] |
| Power (Watts) | 7.7 W [1] |
| Product Status | Active [1] |
| RPM | 3100 RPM [1] |
| Series | OD1225 [1] |
| Size / Dimension | Square - 120mm L x 120mm H [1] |
| Static Pressure | 0.240 in H2O (59.8 Pa) [1] |
| Termination | 2 Wire Leads [1] |
| Voltage - Rated | 24VDC [1] |
| Voltage Range | 15 ~ 25VDC [1] |
| Weight | 0.341 lb (154.67 g) [1] |
| Width | 25.00mm [1] |
Specification references[1]Orion Fans OD1225-24HB vendor product record ↗
