Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Air Flow | 110.0 CFM (3.08m³/min) [1] |
| Approval Agency | cURus, TUV [1] |
| Base Product Number | OA4715 [1] |
| Bearing Type | Ball [1] |
| Current Rating (Amps) | 0.300A [1] |
| Fan Type | Tubeaxial [1] |
| Material - Frame | Aluminum [1] |
| Mfr | Orion Fans [1] |
| Lifetime @ Temp. | 60000 Hrs @ 40°C [1] |
| Noise | 44.0dB [1] |
| Power (Watts) | 24.00W [1] |
| Material - Blade | Polybutylene Terephthalate (PBT) [1] |
| Product Status | Active [1] |
| RPM | 3000 RPM [1] |
| Series | OA4715 [1] |
| Operating Temperature | 14~158°F(-10~70°C) [1] |
| Size / Dimension | Square - 120mm L x 120mm H [1] |
| Static Pressure | 0.370 in H2O (92.2 Pa) [1] |
| Termination | 2 Terminals [1] |
| Voltage - Rated | 120VAC [1] |
| Weight | 1.2 lbs (544.3 g) [1] |
| Width | 38.00mm [1] |
Specification references[1]Orion Fans OA4715-12TB vendor product record ↗
