Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Air Flow | 62.1 CFM (1.74m³/min) [1] |
| Bearing Type | Sintec [1] |
| Base Product Number | NYW14025012 [1] |
| Current Rating (Amps) | 0.070A [1] |
| Fan Type | Tubeaxial [1] |
| Lifetime @ Temp. | 50000 Hrs @ 40°C [1] |
| Material - Blade | Polybutylene Terephthalate (PBT) [1] |
| Material - Frame | Polybutylene Terephthalate (PBT) [1] |
| Mfr | YS TECH USA [1] |
| Noise | 21.7dB(A) [1] |
| Power (Watts) | 840 mW [1] |
| Product Status | Active [1] |
| RPM | 1050 RPM [1] |
| Series | NYW14025 [1] |
| Size / Dimension | Square - 140mm L x 140mm H [1] |
| Static Pressure | 0.051 in H2O (12.7 Pa) [1] |
| Termination | 2 Wire Leads [1] |
| Voltage - Rated | 12VDC [1] |
| Voltage Range | 7 ~ 13.2VDC [1] |
| Width | 25.00mm [1] |
Specification references[1]YS TECH USA NYW14025012LL-12 vendor product record ↗
