Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Air Flow | 2.6 CFM (0.073m³/min) [1] |
| Bearing Type | Sintec [1] |
| Base Product Number | NYW03010005 [1] |
| Current Rating (Amps) | 0.080A [1] |
| Fan Type | Tubeaxial [1] |
| Lifetime @ Temp. | 50000 Hrs @ 40°C [1] |
| Material - Blade | Polybutylene Terephthalate (PBT) [1] |
| Material - Frame | Polybutylene Terephthalate (PBT) [1] |
| Mfr | YS TECH USA [1] |
| Noise | 17.0dB(A) [1] |
| Power (Watts) | 400 mW [1] |
| Product Status | Active [1] |
| RPM | 6000 RPM [1] |
| Series | NYW03010 [1] |
| Size / Dimension | Square - 30mm L x 30mm H [1] |
| Static Pressure | 0.079 in H2O (19.6 Pa) [1] |
| Termination | 2 Wire Leads [1] |
| Voltage - Rated | 5VDC [1] |
| Voltage Range | 4 ~ 5.5VDC [1] |
| Width | 10.50mm [1] |
Specification references[1]YS TECH USA NYW03010005LL-6 vendor product record ↗
