Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Type | Open Frame [1] |
| Applications | ITE (Commercial) [1] |
| Voltage - Input | 85 ~ 264 VAC [1] |
| Approval Agency | CB, CE, cUL, UKCA, UL [1] |
| Voltage - Output 1 | 24V [1] |
| Current - Output 1 | 5.4 A [1] |
| Mounting Type | Chassis Mount [1] |
| Efficiency | 90% [1] |
| Features | Remote On/Off, Standby Output, Universal Input [1] |
| Mfr | Magic Power [1] |
| Minimum Load Required | No [1] |
| Number of Outputs | 1 [1] |
| Operating Temperature | -20°C ~ 80°C (With Derating) [1] |
| Part Status | Active [1] |
| Power (Watts) | 130W [1] |
| Size / Dimension | 4.00" L x 2.00" W x 1.35" H (101.6mm x 50.8mm x 34.3mm) [1] |
| Series | MPE-S130 (130W) [1] |
| Standard Number | 60950-1; 62368-1 [1] |
| Voltage - Isolation | 3 kV [1] |
Specification references[1]Magic Power MPE-S135-SB vendor product record ↗
