Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Air Flow | 29.0 CFM (0.812m³/min) [1] |
| Approval Agency | CUR, TUV, UL [1] |
| Base Product Number | MA1072 [1] |
| Bearing Type | Vapo-Bearing™ [1] |
| Current Rating (Amps) | 0.197A [1] |
| Fan Type | Tubeaxial [1] |
| Material - Frame | Polybutylene Terephthalate (PBT) [1] |
| Mfr | Sunon Fans [1] |
| Noise | 31.0dB(A) [1] |
| Power (Watts) | 3.70W [1] |
| Product Status | Obsolete [1] |
| RPM | 3900 RPM [1] |
| Series | MagLev® MA [1] |
| Size / Dimension | Square - 70mm L x 70mm H [1] |
| Static Pressure | 0.180 in H2O (44.8 Pa) [1] |
| Termination | 2 Wire Leads [1] |
| Voltage - Rated | 115VAC [1] |
| Weight | 0.209 lb (94.89 g) [1] |
| Width | 25.00mm [1] |
Specification references[1]Sunon Fans MA1072-HVL.GN vendor product record ↗
