Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Base Product Number | LOPL-E001 [1] |
| Color | Amber [1] |
| Current - Max | 350mA [1] |
| Current - Test | 350mA [1] |
| Height - Seated (Max) | 0.087" (2.20mm) [1] |
| Lumens/Watt @ Current - Test | 40 lm/W [1] |
| Mfr | Lite-On Inc. [1] |
| Luminous Flux @ Current/Temperature | 36lm (Typ) [1] |
| Mounting Type | Surface Mount [1] |
| Product Status | Obsolete [1] |
| Size / Dimension | 0.315" Dia (8.00mm) [1] |
| Temperature - Test | 25°C [1] |
| Series | LOPL [1] |
| Viewing Angle | 110° [1] |
| Voltage - Forward (Vf) (Typ) | 2.57V [1] |
| Wavelength | 590nm (Typ) [1] |
| Thermal Resistance of Package | 13.7°C/W [1] |
Specification references[1]Lite-On Inc. LOPL-E001A vendor product record ↗
