Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Air Flow | 9.5 CFM (0.266m³/min) [2] |
| Approval Agency | CE, CUR, TUV, UL [2] |
| Bearing Type | Ball [2] |
| Current Rating (Amps) | 0.100A [2] |
| Fan Type | Tubeaxial [2] |
| Material - Blade | Polybutylene Terephthalate (PBT) [2] |
| Material - Frame | Polybutylene Terephthalate (PBT) [2] |
| Mfr | Sunon Fans [2] |
| Noise | 28.9dB(A) [2] |
| Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) [2] |
| Power (Watts) | 1.2 W [2] |
| Product Status | Obsolete [2] |
| RPM | 5000 RPM [2] |
| Series | KD [2] |
| Size / Dimension | Square - 50mm L x 50mm H [2] |
| Static Pressure | 0.100 in H2O (24.9 Pa) [2] |
| Termination | 2 Wire Leads [2] |
| Voltage - Rated | 12VDC [2] |
| Voltage Range | 5 ~ 13.8VDC [2] |
| Weight | 0.051 lb (23.13 g) [2] |
| Width | 10.50mm [2] |
Specification references[1]KD1205PFB2 H delivered document ↗[2]Sunon Fans KD1205PFB2 H vendor product record ↗
