KBB5020A representative package visual — not an exact-product photograph
Representative package visual — not an exact-product photographProduct referenceVendor-delivered DigiKey product/package image
Exact MPN9 sourced attributes1 source document

Focus LCDs · exact orderable part

KBB5020A

20-PIN FPC BREAKOUT BOARD

Base Product Number
KBB50
Board Thickness
0.062" (1.57mm) 1/16"
Number of Positions
20
Package Accepted
FPC Connector
Pitch
0.020" (0.50mm)
Product Status
Active
Original manufacturerCommercial terms confirmed per lot
ManufacturerFocus LCDs
PackingBox

Technical parameters

Technical specifications

9 normalized values · 1 validated source

Report a data issue
ParameterValue
Base Product NumberKBB50 [1]
Board Thickness0.062" (1.57mm) 1/16" [1]
MfrFocus LCDs [1]
Number of Positions20 [1]
Package AcceptedFPC Connector [1]
Pitch0.020" (0.50mm) [1]
Product StatusActive [1]
Proto Board TypeConnector to Plated Through Hole [1]
Size / Dimension1.780" L x 2.590" W (45.21mm x 65.71mm) [1]
Specification references[1]Focus LCDs KBB5020A vendor product record ↗
