Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Base Product Number | K22X-B25 [1] |
| Backset Spacing | 0.318" (8.08mm) [1] |
| Color | Black [1] |
| Connector Style | D-Sub [1] |
| Connector Type | Plug, Male Pins [1] |
| Contact Finish | Gold [1] |
| Contact Finish Thickness | Flash [1] |
| Contact Material | Brass [1] |
| Contact Type | Signal [1] |
| Current Rating (Amps) | 2A [1] |
| Dielectric Material | Polybutylene Terephthalate (PBT), Glass Filled [1] |
| Flange Feature | Housing/Shell (4-40) [1] |
| Features | Board Lock, Grounding Indents [1] |
| Material Flammability Rating | UL94 V-0 [1] |
| Mfr | Kycon, Inc. [1] |
| Mounting Type | Through Hole, Right Angle [1] |
| Number of Positions | 25 [1] |
| Number of Rows | 2 [1] |
| Operating Temperature | -55°C~105°C [1] |
| Product Status | Active [1] |
| Series | K22X [1] |
| Shell Material, Finish | Steel, Nickel Plated [1] |
| Shell Size, Connector Layout | 3 (DB, B) [1] |
| Termination | Solder [1] |
| Voltage Rating | 30V [1] |
Specification references[1]Kycon, Inc. K22X-B25P-N vendor product record ↗
