Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Base Product Number | ISOW7841 [1] |
| Channel Type | Unidirectional [1] |
| Common Mode Transient Immunity (Min) | 100kV/µs [1] |
| Data Rate | 100Mbps [1] |
| Inputs - Side 1/Side 2 | 3/1 [1] |
| Isolated Power | Yes [1] |
| Mfr | Texas Instruments [1] |
| Mounting Type | Surface Mount [1] |
| Number of Channels | 4 [1] |
| Operating Temperature | -40°C~125°C [1] |
| Product Status | Active [1] |
| Propagation Delay tpLH / tpHL (Max) | 17.6ns, 17.6ns [1] |
| Rise / Fall Time (Typ) | 2ns, 2ns [1] |
| Pulse Width Distortion (Max) | 4.7ns [1] |
| Series | Automotive, AEC-Q100 [1] |
| Technology | Capacitive Coupling [1] |
| Type | General Purpose [1] |
| Voltage - Isolation | 5000Vrms [1] |
| Voltage - Supply | 3V ~ 5.5V [1] |
Specification references[1]Texas Instruments ISOW7841FAQDWERQ1 vendor product record ↗
