Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Applications | ITE (Commercial) [1] |
| Base Product Number | IQG48042 [1] |
| Current - Output (Max) | 42A [1] |
| Efficiency | 95% [1] |
| Features | OCP, SCP [1] |
| Mfr | TDK-Lambda [1] |
| Mounting Type | Through Hole [1] |
| Number of Outputs | 1 [1] |
| Operating Temperature | -40°C ~ 125°C [1] |
| Power (Watts) | 504 W [1] |
| Part Status | Active [1] |
| Series | iQG (504W) [1] |
| Size / Dimension | 2.28" L x 1.45" W x 0.52" H (57.9mm x 36.8mm x 13.2mm) [1] |
| Type | Intermediate Bus Converter [1] |
| Voltage - Input (Max) | 75V [1] |
| Voltage - Input (Min) | 36V [1] |
| Voltage - Isolation | 1.5 kV [1] |
| Voltage - Output 1 | 12V [1] |
| Package / Case | 8-DIP Module, 1/4 Brick [1] |
Specification references[1]TDK-Lambda IQG48042A120V-1U9-R vendor product record ↗
