Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Current - DC Forward (If) (Max) | 60 mA [1] |
| Current - Output / Channel | 150mA [1] |
| Current Transfer Ratio (Min) | 20% @ 10mA [1] |
| Input Type | DC [1] |
| Mfr | Lite-On Inc. [1] |
| Mounting Type | Surface Mount [1] |
| Number of Channels | 1 [1] |
| Operating Temperature | -55°C~100°C [1] |
| Output Type | Transistor with Base [1] |
| Series | H11AX [1] |
| Product Status | Obsolete [1] |
| Rise / Fall Time (Typ) | 2.8µs, 4.5µs [1] |
| Vce Saturation (Max) | 400mV [1] |
| Voltage - Forward (Vf) (Typ) | 1.2V [1] |
| Voltage - Isolation | 5000Vrms [1] |
| Voltage - Output (Max) | 30V [1] |
Specification references[1]Lite-On Inc. H11A2S-TA1 vendor product record ↗
