Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Air Flow | 49.0 CFM (1.37m³/min) [1] |
| Bearing Type | Ball [1] |
| Current Rating (Amps) | 0.230A [1] |
| Fan Type | Tubeaxial [1] |
| Features | Speed Sensor (Tach) [1] |
| Mfr | Comair Rotron [1] |
| Noise | 33.0dB(A) [1] |
| Power (Watts) | 2.8 W [1] |
| Product Status | Obsolete [1] |
| RPM | 2800 RPM [1] |
| Series | Gryphon [1] |
| Size / Dimension | Square - 92mm L x 92mm H [1] |
| Static Pressure | 0.120 in H2O (29.9 Pa) [1] |
| Termination | 3 Wire Leads [1] |
| Voltage - Rated | 12VDC [1] |
| Voltage Range | 6 ~ 13.8VDC [1] |
| Weight | 0.187 lb (84.82 g) [1] |
| Width | 25.00mm [1] |
Specification references[1]Comair Rotron GDA9225-12BB vendor product record ↗
